Deep Well Pump

Product Features

High Efficiency & Energy Saving: Superior energy performance

Compact & Space-Saving Design: Minimal footprint

Quick Disassembly: Motor and pump share identical dimensions for seamless servicing

Simplified Installation & Maintenance: User-friendly operation

Applications

Water supply from wells or reservoirs

Domestic, civil, and industrial water systems

Garden and agricultural irrigation

Operating Conditions

Maximum liquid temperature: 35°C

Maximum sand content: 2% (by weight)

Maximum submersion depth: 120 meters

Power Supply:①Frequency: 50Hz②Single-phase AC: 220V | Three-phase AC: 380V③Voltage fluctuation tolerance: ±10%

Motor & Pump Specifications

Motor:Single-phase: 220V/50Hz；Three-phase: 380V/50Hz

Control System: Manual control box or digital automatic controller

Pump Construction:①Reinforced stainless steel pump casing②Multi-stage floating impeller design③High-strength engineering
